Hikvision DS-9664NI-I8 12MP 64 Channel NVR Recorder Ultra Series

Hikvision NVR DS-9664NI-I8 Ultra Series supports 12MP record resolution and 64 Channels. Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera Advanced streaming technology enables smooth live view in poor network conditions.

Hikvision DS-9664NI-I8 Specifications:

• Up to 64 channel IP cameras can be connected
• Up to 12 MP high-definition live view, storage, and playback
• Up to 320 Mbps (or 200 Mbps when RAID is enabled) high incoming bandwidth ensures IP cameras can be connected
• 2 HDMI (different source) and 2 VGA (different source) interfaces
• 8 HDDs can be used for continuous video recording
• Supports RAID 0, 1, 5, 6, 10, and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks

Video And Audio

• IP Video Input 64-ch Up to 12 MP resolution
• HDMI 1 Output HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60HzVGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,HDMI 2 Output 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,2-ch, RCA (2.0Vp-p, 1 KΩ)
• VGA Output HDMI, VGA
• CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Incoming Bandwidth 320 Mbps or 200 Mbps (when RAID is enabled),256 Mbps, or 200 Mbps (when RAID is enabled)
• Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

• Decoding Format 265+, H.265,H.264+, H.264
• Decoding Capability 2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
• Synchronous Playback 16-ch
• Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Network

• Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• Remote Connection 128
• Network Interface 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

Auxiliary Interface

• SATA 8
• ESATA 1 eSATA interface
• Capacity Up to 10 TB capacity for each HDD
• Serial Interface RS-232; RS-485; Keyboard
• USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
• Alarm In/Out 16/4

General

• Power Supply 100 to 240 VAC, 50 to 60 Hz 200 W
• Consumption ≤ 30 W
• Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity 10 to 90 %
• Chassis 2U
• Dimension (W × D × H) 445 × 470 ×90 mm (17.5″× 18.5″ × 3.5″)
• ≤ 10 kg (22 lb)
