Hikvision DVR DS-7204HUHI-K1/P model has 1 hard drive and 4 different channels. With H.265 pro compression technology, you can save your recordings from 1 to 6 TB on your internal storage.
Definition output through 5 signals input adaptive to (HDTVI/AHD/CVI/CVBS/IP) can be encoded up to 5MP @12 frames per second. This DVR model has automatic power supply management for the POC cameras to guarantee safety, plus it has up to 2 channel 6MP ONVIF conformant IP cameras input.
Features:
- 4 channels and 1 HDD 1U DVR
- Efficient H.265 pro and compression technology
- Encoding ability up to 5 MP @ 12 fps
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Up to 8 network cameras can be connected
- Transmits both HDTVI video and power over the same coaxial cablee
Hikvision DS-7204HUHI-K1/P Specifications:
Recording
- Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding resolution
- 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF
- 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Video and Audio
- Video and Audio
- IP video input4-ch (up to 8-ch); Up to 8 MP resolution, The 8 MP signal input is only available for channel 1 of DS-7204HUHI-K1/P., Support H.265+/H.265/H.264+/H.264 IP cameras
- Analogue video input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- AHD input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI input4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS input PAL/NTSC
- HDMI/VGA output1-ch,2K (2560 × 1440)/60Hz,1920 × 1080/60Hz,1280 × 1024/60Hz,1280 × 720/60Hz,,1024 × 768/60Hz,
- Audio input4-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio output1-ch, RCA (Linear, 1 KΩ)
- Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Synchronous playback4-ch
- HDTVI input8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
- VGA/HDMI output1-ch,2K (2560 × 1440)/60Hz,1920 × 1080/60Hz,1280 × 1024/60Hz,1280 × 720/60Hz,1024 × 768/60Hz
- PoC camera input Support Hikvision PoC camera, PoC access capability, see Appendix.,
- CVBS output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Network
- Remote connections32
- Network protocols TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPâ„¢, HTTPS, ONVIF
- Network interface1,RJ45 10M/100M, self-adaptive, Ethernet interface,
Auxiliary Interface
- SATA1 SATA interface
- Capacity Up to 10 TB capacity for each disk
- Alarm in/out4/1
- USB interface2 × USB 2.0
- Serial interfaceRS-485 (half-duplex)
